Model |
LaCam 4HT |
Version |
New |
Ranging Method |
Time-of-flight |
Laser wavelength |
1550nm |
Laser Pulse Repetition Rate |
300,000 Hz |
Scan Rate |
135,000 Hz |
Single Point range accuracy(peak-peak) |
5mm |
Precision |
2
mm |
Max. Measurable range |
20 |
Min. Measurable range |
0.5 |
Angular Pointing Accuracy |
0.0005° |
Horizontal field of view |
360° |
Vertical Filed of view |
-65° / +45° (110°) |
Min. angle step-width |
0.0024° |
Beam diameter |
3.7mm |
Laser safety class |
Class 1 |
Interface |
Ethernet, 12 - 28 V power |
Optical Geometry |
Single
channel-send/receive optical paths coaxial |
State of-the-art components |
Fiber laser, Signal processing electronics with echo digitization and
online waveform analysis, High precision encoders |
Physical configuration |
LaCam 4 HT
is designed as replacement for the LaCam 2ki in all of Ferrotron system
if required |
Options |
all LaCam
Laserheads offer the option of a Pyrometer Temperature Measurement
channel which is built in the laserhead and allows the measurement of
the surface temperatures between 500°C and 1700°C with thesame
resolution of the distance scan |
